Wood-burning thermo stoves
Rizzoli T Line Basic 25 KW stove
T range Manual
T range Stove features
T Range Data Sheet
Wood-burning thermo stoves
Basic
T Rock is characterized by a Serpentine stone covering that gives a perfect balance between steel, stone and glass.
The T range is extremely compact, elegant, versatile and modern. Available with or without an oven.
Technologies
Partners
Technical Specifications
- Certified combustion system – H2O System®
- High thickness steel boiler
- Boiler protections in steel
- Hermetical combustion chamber
- Upper flue outlet
- Cast iron fire grill
- External air intake predisposition – External air®
- Automatic comburent air regulation – Air control®
- Regulation/closure external air intake
- Primary, secondary and tertiary air
- Fire door with double ceramic glass
- Fire door with self-cleaning system – Shiny Glass®
- Fire door and ash door with hermetical closure
- Thermal drain predisposition
- Wood chunks length till 40 cm
- Variable wood load with grill riser system
- Always cold handles thermally isolated
- Wide extractable ash drawer
- Levelling pins
- 6 years warranty on boiler body
Technical Data
- Length: 490 mm
- Height: 1206 mm
- Width: 600 mm
- Combustion chamber (LxWxH): 244x372x411 mm
- Total Nominal Power: 9,1-25,9 kW
- Water Nominal Power: 2,0-17,1 kW
- Heating Nominal power: 7,1-8,9 kW
- Efficiency: 85,1-76,1 %
